High-Efficiency Shell and Tube Heat Exchangers for Industrial Applications

Our standard shell and tube series is built upon highly standardised components. These standardised components allow us to provide products of exceptional quality at both reasonable prices and fast delivery times. With many sizes and types in inventory, we can provide rapid solutions for many applications.

More Information

For more information about our standard shell & tube heat exchangers, download our brochure.
Shell and Tube Heat Exchanger

Standard Shell & Tube: Type BCF

This exchanger is designed for small cooling applications, such as hydraulic fluid.

  • Tubes
    • 0.2 to 3.6 m long
    • 90/10 & 70/30 Cu/Ni
    • 6, 10, & 16 mm diameter
    • Design P = 10 bar
    • Design T = 150°C
  • Brass shell
    • 50 – 200 mm diameter
    • Design P = 20 bar
    • Design T = 150°C
  • Brass hubs optional SAE connections
  • Cast iron or bronze bonnets
  • Standard sizes for fast delivery
Shell and Tube Heat Exchanger

Standard Shell & Tube: Type SSCF

This exchanger is designed for a wide range of applications such as pharmaceutical or ammonia service. It is highly standardised however many options exist.

  • Tubes
    • 0.2 to 3.6 m long
    • Copper, 90/10 & 70/30 Cu/Ni, or SS316
    • 6, 10, & 16 mm diameter
    • Design P = 10 bar
    • Design T = 230°C
  • SS316 shell
    • 50 – 200 mm diameter
    • Design P = 20 bar
    • Design T = 230°C
  • Brass hubs optional SAE connections
  • Cast SS316 hubs
  • Cast SS316, iron, or bronze bonnets
Shell and Tube Heat Exchanger

Standard Fabricated Shell & Tube: Type SX2000

The SX2000 tube type heat exchanger is fully fabricated instead of utilising the standard castings offered in the above two models. Fabrication allows for many more options but the delivery times can be slightly longer than the above options.

  • Tubes
    • 0.2 to 3.6 m long
    • Copper, 90/10 Cu/Ni, or SS316
    • 6, 10 mm diameter
    • Design P = 10 bar
    • Design T = 230°C
  • Carbon steel shell
    • 50 – 200 mm diameter
    • Design P = 20 bar
    • Design T = 230°C
  • 90/10 Cu/Ni, carbon steel, or SS316 tubesheet
  • Cast SS316, iron, or bronze bonnets
Shell and Tube Heat Exchanger

Standard U-tube: Type B300

Our U-tube type heat exchanger can be built to large sizes, its design allows for fast delivery and extremely competitive prices. Having a single tube plate makes it perfect for temperature cycling in service.

  • Tubes
    • Copper, 90/10 & 70/30 Cu/Ni, or SS316
    • 3 & 19 mm diameter
    • Design P = 10 bar
    • Design T = 190°C
  • Carbon steel or SS316 shell
    • 100 – 800 mm diameter
    • Design P = 10 bar
    • Design T = 190°C
  • Brass, 90/10 Cu/Ni, carbon steel, or SS316 tubesheet
  • Cast SS316, iron, or bronze bonnets
